Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork

Certification
China ANPING COUNTY JIAFU WIRE MESH MANUFACTURING CO.,LTD certification
China ANPING COUNTY JIAFU WIRE MESH MANUFACTURING CO.,LTD certification
I'm Online Chat Now

Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork

Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork
Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork

Large Image :  Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork

Product Details:
Place of Origin: ANPING HEBEI CHINA
Brand Name: XINGTAI
Model Number: XTH20
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Packaging Details: 500-1000PCS/PALLET
Delivery Time: 15-20DAYS
Supply Ability: 5000PCS/DAY
Detailed Product Description
MATERIAL: Hot Galvanized Plate WIDTH: 0.45M
Length: 2-3m Color: Silver
Thickness: 0.18-0.57mm Rib Height: 14-20mm
High Light:

hy rib lath

,

hy rib formwork

Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork

HY Rib Mesh is manufactured from hot-dipped galvanized steel sheets. Because its meshes and U patterns, it has better anti-stress capability and forming flexibility than normal metal lath. This product has excellent engineering quality, construction security and widely used in tunnels bridges, valve basement systems, sewage systems, subways, retaining walls, nuclear power plants, shipyards, water pools and marine engineering works and high rise building projects and non-regular or bending pattern etc. As concrete permanent assembly-free form work.



Specification:



Thickness:0.18-0.57mm

Rib Height:14-20mm

Width:0.45m

Length:1m-4m

packing:500 or 1000pcs/pallet



Model Thickness (mm) Weight (kg) Width (mm) Length (mm) Rib Height (mm) Rib Distance(mm)
018 0.18 1.35 450 2200 15 90
021 0.21 1.60 450 2200 15 90
023 0.23 1.70 450 2200 15 90
025 0.25 1.90 450 2200 15 90
030 0.30 2.45 450 2200 15 90
035 0.35 2.90 450 2200 15 90
0.40 0.40 3.30 450 2200 15 90



Model Thickness (mm) Weight (kg) Width (mm) Length (mm) Rib Height (mm) Rib Distance(mm)
2021 0.21 1.70 450 2200 20 90
2023 0.23 1.90 450 2200 20 90
2025 0.25 2.10 450 2200 20 90
2030 0.30 2.50 450 2200 20 90
2035 0.35 2.90 450 2200 20 90
2040 0.40 3.40 450 2200 20 90
2045 0.45 3.80 450 2200 20 90
2050 0.50 4.10 450 2200 20 90
2057 0.57 4.70 450 2200 20 90






Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork 0



How to Install HY Rib Mesh ?Galvanized HY Rib Mesh Construction Joint 0.18-0.57mm Thickness Assembly - Free Formwork 1
