Product Details:
Payment & Shipping Terms:
|
| Material: | Hot-dipped Galvanized Sheet | Thinckness: | 0.3mm |
|---|---|---|---|
| Width: | 610mm | Length: | 2.1m-2.5m |
| High Light: | flat rib lath,rib lath cladding |
||
| Could you tell us the thickness, Hole size, Rib distance , Width x length request? | ||
| (7 rib 8 opening, 5 rib 8 opening, 9 rib 4 opening, 7 rib 4 opening) | ||
| Weight Per Square Yard | ||
| 2.75 lb. / sy | Flat Rib | Galvanized |
| 3.4 lb. / sy | Flat Rib | Galvanized |
| 3.4 lb. / sy | 3/8" High Rib | Galvanized |
| 4.0 lb. / sy | 3/8" High Rib | Galvanized |
Most Popular
| Thickness(mm) | Rib Distance(mm) | Weight(KG) | Width X length(mm) |
| 0.30 | 100 | 1.79 | 610 x 2440 |
| 0.35 | 100 | 2.09 | 610 x 2440 |
| 0.40 | 100 | 2.38 | 610 x 2440 |
| 0.45 | 100 | 2.68 | 610 x 2440 |
| 0.5 | 100 | 2.98 | 610 x 2440 |
| Thickness(mm) | Rib Distance(mm) | Weight(KG) | Width X length(mm) |
| 0.30 | 150 | 1.31 | 610 x 2440 |
| 0.35 | 150 | 1.53 | 610 x 2440 |
| 0.40 | 150 | 1.75 | 610 x 2440 |
| 0.45 | 150 | 1.96 | 610 x 2440 |
| 0.5 | 150 | 2.17 | 610 x 2440 |
Application:
Widely used as a background for plaster, render, stucco application in construction of suspended ceilings partition.
