| Width: | 450MM | Length: | 1-4M |
|---|---|---|---|
| Rib Height: | 15MM | Hole: | 5*10MM |
| Material: | Galvanized Sheet | Rib Distance: | 90mm |
| High Light: | Construction hy rib formwork,hy rib formwork Mesh,2.5m Length hy rib formwork |
||
1. Material: Hot-dipped galvanized sheet
2. Application:
1). Construction formwork mesh has very good engineering quality and construction security;
2). Construction formwork mesh as the concrete permanent assembly
free sheet is much convenient for engineering design and processing;
3). Construction formwork mesh is widely used in tunnels, bridges and valve system and so on
to make the process of construction much more fast and stable.
3. Specification
| Model |
Thickness (mm) |
Weight (kg) | Width (mm) | Length (mm) | Rib Height(mm) |
Rib Distance (mm) |
| 021 | 0.21 | 1.70 | 450 | 2200 | 14-20 | 90 |
| 023 | 0.23 | 1.90 | 450 | 2200 | 14-20 | 90 |
| 030 | 0.30 | 2.48 | 450 | 2200 | 14-20 | 90 |
| 035 | 0.35 | 2.90 | 450 | 2200 | 14-20 | 90 |
| 040 | 0.40 | 3.30 | 450 | 2200 | 14-20 | 90 |
| 045 | 0.45 | 3.70 | 450 | 2200 | 14-20 | 90 |
| 050 | 0.50 | 4.10 | 450 | 2200 | 14-20 | 90 |
Features of High Ribbed Formwork
Because its meshes and U patterns, it has better anti-stress capability and forming flexibility than normal metal lath. This product has excellent engineering quality, construction security and widely used in tunnels bridges, valve basement systems, sewage systems, subways, retaining walls, nuclear power plants, shipyards, water pools and marine engineering works and high rise building projects and non-regular or bending pattern etc. As concrete permanent assembly-free form work.
