Construction Expanded Metal Screen Brickwork Reinforcement Mesh 80mm Width

Large Image : Construction Expanded Metal Screen Brickwork Reinforcement Mesh 80mm Width

Product Details:

Place of Origin:	Heibei
Brand Name:	Xingtai
Certification:	IS9001.2000
Model Number:	XT-80

Payment & Shipping Terms:

Minimum Order Quantity:	500ROLLS
Packaging Details:	PLATE CARTON
Delivery Time:	10DAYS
Payment Terms:	D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability:	5000ROLLS/WEEK

Contact Now

Detailed Product Description

Material:	Hot Dip Galvanized Steel	Mesh Size:	12x25mm
Width:	80mm	Length:	40M
Packing:	Carton	Weigh:	380g/m2
High Light:	brick wall reinforcing mesh , brick wire mesh

Description

Brick Wire Mesh is easy to handle, and when laid embedded in the mortar joining between brickwork or blockwore courses, forms an integral structure of great tcnsilc strcngth which assists in the resistance, vibrations and thermal changes.

Laid on the mortar bed with 25mm clearance to the outside face of the wall and lapped ant least 75mm, if joining lengths. The reinforcement is then embedded completely and for most applications, every third course is suffcient.

Advantages

It is expanded steel mesh with continuity of steel.
It has no joints, welds or interweaving to fail under stress.
The mesh is anchored immovably so that the reinforcement cannot slip under tension.
This is the only type of brickwork reinforcement to give such a unique combination of all these advantages.

MODEL	MESHSIZE MM	WIDTH MM	LENGTH Meter	THICKNESS MM
XT-65	12X25	65	20-100	0.3/0.5
XT-80	12X25	80	20-100	0.3/0.5
XT-100	12X25	100	20-100	0.3/0.5
XT-150	12X25	150	20-100	0.3/0.5
XT-200	12X25	200	20-100	0.3/0.5
