Product Details:
Payment & Shipping Terms:
|
| Width: | 450MM | Length: | 1-4M |
|---|---|---|---|
| Rib Height: | 15MM | Hole: | 5*10MM |
| Material: | Galvanized Sheet | Rib Distance: | 90mm |
| High Light: | high rib mesh,high rib sheet |
||
Material of High Rib Mesh:
Hot dipped galvanized sheet
Application of High Rib Mesh
Suitable for segmental construction joints of concrete pouring lien
Applicable to place concrete isolation of post-cast strip profile
Applicable to the construction site temporary lien various cracks, voids
Different concrete between the spacer
Specification of High Rib Mesh
Width: 450mm is usual, 440mm and 445mm also can be made
Length: 1m-3m
Thickness:0.15mm,0.2mm,0.25mm,0.3mm,0.35mm ,0.40mm,0.57mm
The follows is the 2.2 m goods weight for your reference:
| del | Thickness (mm) | Weight (kg) | Width (mm) | Length (mm) | Rib Height (mm) | Rib Distance(mm) |
| 021 | 0.21 | 1.70 | 450 | 2200 | 15 | 90 |
| 023 | 0.23 | 1.90 | 450 | 2200 | 15 | 90 |
| 030 | 0.30 | 2.48 | 450 | 2200 | 15 | 90 |
| 035 | 0.35 | 2.90 | 450 | 2200 | 15 | 90 |
| 040 | 0.40 | 3.30 | 450 | 2200 | 15 | 90 |
Rib distance
Rib Height
Features of High Ribbed Formwork
Because its meshes and U patterns, it has better anti-stress capability and forming flexibility than normal metal lath. This product has excellent engineering quality, construction security and widely used in tunnels bridges, valve basement systems, sewage systems, subways, retaining walls, nuclear power plants, shipyards, water pools and marine engineering works and high rise building projects and non-regular or bending pattern etc. As concrete permanent assembly-free form work.
