90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction

Certification
China ANPING COUNTY JIAFU WIRE MESH MANUFACTURING CO.,LTD certification
China ANPING COUNTY JIAFU WIRE MESH MANUFACTURING CO.,LTD certification
I'm Online Chat Now

90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction

90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction
90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction

Large Image :  90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction

Product Details:
Place of Origin: ANPING HEBEI CHINA
Brand Name: JiaFu
Model Number: JFH21
Payment & Shipping Terms:
Minimum Order Quantity: 500PCS
Packaging Details: 500 OR 100PCS/PALLET
Delivery Time: 10-15DAYS
Supply Ability: 3000PCS/DAY
Detailed Product Description
Width: 450MM Length: 1-4M
Rib Height: 15MM Hole: 5*10MM
Material: Galvanized Sheet Rib Distance: 90mm
High Light:

90mm rib distance hy rib mesh

,

0.4mm thickness hy rib mesh

,

construction high rib mesh

90mm Rib Distance HY Rib Mesh450mm Width 0.4mm Thickness For Construction

HY Rib Mesh is  made by professional machine.Because its meshes and U patterns, it has better anti-stress capability and forming flexibility than normal metal lath. This product has excellent engineering quality, construction security and widely used in tunnels bridges, valve basement systems, sewage systems, subways, retaining walls, nuclear power plants, shipyards, water pools and marine engineering works and high rise building projects and non-regular or bending pattern etc. As concrete permanent assembly-free form work.





Material of HY Rib Mesh:



Hot dipped galvanized sheet





Specification of HY Rib Mesh:



Width: 450mm

Length: 1m-3m
Thickness:0.15mm,0.2mm,0.25mm,0.3mm,0.35mm ,0.40mm,0.57mm



The follows is the 2.2 m goods weight for your reference:



del Thickness (mm) Weight (kg) Width (mm) Length (mm) Rib Height (mm) Rib Distance(mm)
021 0.21 1.70 450 2200 15 90
023 0.23 1.90 450 2200 15 90
030 0.30 2.48 450 2200 15 90
035 0.35 2.90 450 2200 15 90
040 0.40 3.30 450 2200 15 90

90mm Rib Distance Hy Rib Mesh 450mm Width 0.4mm Thickness For Construction 0
